The extremely robust mulch shredder is used to crush and spread straw, beet leaves, potato haulm, grass and green manure. Due to the extremely massive design of the rotor shaft and the housing, the device is particularly suitable for hard continuous use, even in large-scale farms.

The mulch shredder has been developed for high working speeds with low effort and therefore convinces with a large area performance. The large rotor with high cutting speed is responsible for the strong suction and the very good cutting quality. The heavy rotor shaft is perfectly balanced to guarantee smooth operation. Narrow, long universal blades and a Hardox counter-edge provide fine and optimal shredding performance. A support roller and additional skids ensure the exact ground clearance.

APPLICATION

shredding straw and green manure

FEATURES

extremely solid rotor and robust housing

high cutting speed

smooth running

for front and rear attachment

automatic V-belt tensioner

ADVANTAGES

extremely long service life

accurate ground clearance thanks to adjustable supporting roller

even distribution of shredded mass

great area performance

very fine chopping work due to high cutting speed

Working width [m] 3.0
Rotor diameter [mm] 660
Cutting speed [km/h] / [m/s] 250/70
Housing sheet thickness [mm] 6
Side plate thickness [mm] 15
Number of knives 68
Number of counterknives 2 (one of Hardox)
Height adjustment Supporting roller and skids
Number of support wheels (by arrangement) 4 wheels (360° rotatable)
Automatic V-belt tensioner Standard
Front and rear attachment Standard
Drive shaft Standard
Power requirement [hp] ab 70 bis 130
Weight [kg] 1,280
  • Complete frame made of steel ST 52 / S355

  • Freely rotatable double support wheels
  • Warning signs with lighting and flashing system
